Recent 'AAEON Technology' News


The NANO-002N from AAEON Technology is an embedded box PC based on the Nano-ITX form factor that follows the Broadwell based NANO-001N. Outstanding performance is guaranteed with the dual-core Intel 6th Gen. ULT series (i3/i5/i7 variants). Featuring a wide array of functionalities, this mini-PC delivers different levels of performance at a low power consumption of 15W. The system can be considered as an industrial NUC.
The BOXER-6403M/6404M series from AAEON are the slim, palm-sized and fanless box PCs utilizing low power consumption Intel® Celeron® J1900/N2807 processors. These Box PCs provide fully integrated Gigabit Ethernet LAN ports enabling communication with up to 4 cameras, while featuring built-in digital I/O (BOXER-6403M only) to control lighting for machine vision applications.
The RTC-1200SK from AAEON Technology is one of the most complete IP65 rugged tablet computers in today's market. With its various I/O's on board ranging from COM and Ethernet to 3 USB ports and a HDMI port, you basically have a complete mobile panel PC/HMI, but then with 2 hot-swappable batteries. The fact that the RTC-1200SK has been designed with customization in mind, this 11.6" work horse will fit your exact needs.
The BOXER-6639 from AAEON Technology is a fanless embedded controller incorporating a high-value desktop processor and wide operating temperature to keep up with Industry 4.0 Automation trend. The BOXER-6639 is powered by 6th Gen Intel® Core™ desktop CPU with longevity support. The flexible mechanical design enables you to change out the CPU in the easiest way possible. With features such as 2 HDMI with 4K resolution and 3 industrial GbE LAN with Intel® industrial-grade I210 chipset this BOXER-6639 aims at delivering superb performance.
Once again, the UP Board bridges the gap between makers, innovators and the Internet of Things with the UP LoRa® gateway. This gateway is a combination of an UP board and the IMST LoRa™ concentrator iC880A. By using the LoRa® technology you can deploy thousands of sensors in the radius of kilometers and connect them to the UP LoRa® solution.
AAEON Technology introduces the OMNI-Family, this is a series of modular and customizable industrial touch panel PCs that simplify the assembly process, optimize dynamic deployment and satisfy customer's multiple requirements.
The BOXER-6638U from AAEON is a high performance industrial box PC which is about 30% smaller than its predecessors. High performance is assured with the Intel® Core™ i3-5010U driving the device, the U-series chip comes with greater power-savings and cost-efficiency. This enhanced processing power is used to power the device's many IOs, most prominent of which includes four COM ports. The BOXER-6638U supports a -20 to 60°C temperature range, and a wide operating voltage between 9 and 24V.

Supporting these enhanced operational parameters is the mechanical construction of the BOXER-6638U. Users wishing to access the device's interior can do so by simply removing screws at the base of the device, with no specialized methods or tools required.


Features
•   Intel® Core™i3-5010U CPU
•  TDP: 15W
•  Fanless
•  4 COM ports
•  2-4 USB3.0 or USB2.0 on front/rear (depending on version)
•  Display interface: VGA, DP
•  Dual gigabit Ethernet
•  Storage devices: mSATA, HDD/SSD
•  Full and half-size Mini-Card, SIM slot (optional for mSATA)
•  Wide temperature support: -20 to 60°C
•  9 to 24VDC supply voltage
•  Dimensions: 197x174x55mm
•  OS: Windows 10 (64 bit), Windows 8.1 (32/64-bit), Windows 7 (32/64-bit), Linux, •  Ubuntu 14.10


Applications
•  Industrial automation
The NANO-001N from AAEON Technology is an embedded box PC based on the Nano-ITX form factor. With a wide array of functionalities, the system is powered by the 5th Generation Intel® Core™ SoC U series with the i3/i5/i7 variants, delivering different levels of performance at a low power consumption of 15W. The system can be considered as an industrial NUC.
UP is a perfect single board computer solution for different domains and products like Robotics, Drone, Machine Vision, Smart Home, Education, Digital Signage, Intelligent Cars and Internet Of Things. The compatibility with Linux, Android, and all the Windows 10 distributions give you great flexibility, scalability and quick time to market.
The RTC-600A from AAEON Technolgy is an 5.7" Android™ powered rugged tablet that's engineered for rough and tough applications. This tablet will prove itself a worthy companion through all kinds of circumstances, defying water, dust, sand, snow and mud during. Even dropping the RTC-600 will not give you the nightmares you normally have dropping your consumer-grade tablet.

The RTC-600A features an ARM® Cortex® dual-core TI® OMAP™ 4470 CPU (up to 1.5 GHz), LPDDR2 1GB SDRAM and 16GB eMMC flash. It can be operated in temperatures from -20° to 60°C, making it a much more durable and practical contender than its "sleeker" counterparts.

The RTC-600A is equipped with WiFi, BlueTooth, GPS/GLONASS and 3G to ensure accurate positioning and fast data response. The docking station will even provide extra (back-up) connectivity through physical Ethernet. Furthermore, the 5MP auto-focus camera with flash will create the right picture for you in any environment.

Next to the optional NFC/Mifare RFID reader, the optionally integrated solid-state 1D/2D barcode reader will read a variety of barcodes. It reads the most popular used barcodes from 1D EAN/UPC to 2D DataMatrix codes. The hot-swappable battery will give you the flexibility to work some extra hours past the obligatory 8-hour work-day.


Features
•  5.7" WXGA (1280 x 720) TFT LCD 420nit display with LED backlight
•   TI® OMAP™ 4470 CPU, up to 1.5GHz
•  LPDDR2 1GB SDRAM, 16GB eMMC flash
•  Projected capacitive multi-touch panel, Gorilla Glass
•  Li-Polymer high capacity battery, up to 8 hours battery life
•  Available with single or dual battery
•  Extended swappable battery, MIL-STD 810G, IP67 compliant
•  GPS/ GLONASS simultaneously
•  WiFi a/b/g/n, BT 4.0, WWAN, 3G & LTE (optional)
•  Light & G-sensor, E-compass, vibrator, 5MP camera
•  1D/2D bar code scanner, MSR/smart card reader (optional)
•  Supports NFC/RFID, variant extensions
•  Docking station (optional)
•  Android 4.2 (Jelly Bean)


Applications
•  Logistic & medical industry
•  Industrial (field) service
•  Warehouse management
•  Construction sites
•  Agriculture
•  POS






Building on two of the most recent form factors on the market, the Qseven and Smart Mobility Architecture (SMARC) form factors, the AQ7-BT and uCOM-BT are AAEON's latest solutions powered by the low-power consuming, yet versatile Intel® Atom™/ Celeron® E3800 processors.

The AQ7-BT measures 70x70mm and supports the Qseven 2.0 design specs/pin layout and is the successor to the AQ7-LN. It uses 50% less power while delivering better performance due to the use of the new chips. Additionally, the board can be operated by a battery to increase mobility.

If the AQ7-BT is still considered too big for your application, the uCOM-BT will be up to the task with its even smaller, SMARC form factor, which measures 82 x 50mm. Designed specifically for use in mobile devices, the board consumes as low as 6W of power and packs functionalities that optimizes on-the-go applications, such as HD audio and FHD displays, wireless capabilities, and I/O expansions. Similar to the AQ7-BT, the uCOM-BT can also run on batteries.


AQ7-BT features
•  Intel® Atom™ E3800 CPU, SoC
•  Onboard DDR3L up to 4GB
•  Gigabit Ethernet
•  18/24-bit single channel LVDS LCD/eDP, DDI
•  High definition audio interface
•  2 SATA, one for onboard SSD
•  6 USB2.0, USB3.0, LPC/GPIO, 3 PCI-Express [x1]
•  Qseven Rev. 2.0, dimensions: 70mm x 70mm



uCOM-BT features
•  Intel® Atom™ E3800 & N2807 CPU family, SoC
•  Onboard DDR3L up to 4GB
•  Gigabit Ethernet
•  18/24-bit single channel LVDS, HDMI
•  High definition audio interface
•  2 SATA
•  2 USB2.0, USB3.0, GPIO up to 12-bit
•  3 PCI-Express [x1]
•  SMARC Spec v1.1, dimensions: 82mm x 50mm


Applications
The AQ7-BT and uCOM-BT are optimized for applications demanding compactness, low power consumption and mobility. They perfectly suit application such as handheld devices, robotic arms and portable testing equipment.
AAEON introduces the BOXER-6404 embedded PC one of the smallest, most compact embedded PC’s on the market, measuring only 166 x 106.6 x 30 mm.

The boxer-6404 has a quad core Intel® Celeron® J1900 CPU which provides adequate computing power capabilities. The boxer supports dual display via the 2 system’s HDMI video output and has 4 LAN ports. An additional stock keeping unit with the dual core Intel® Celeron® N2807 is also available for less demanding applications.

The enclosure is entirely made from aluminum. This design, combining with the low power consuming CPU, does not only allows a fanless configuration, but also effectively extends its operating temperature to -20°C ~ 60°C, a range wider than most other on the market.


Features
•   Slim Boxer Design: 30mm
•   Operate in -20°C ~ 60°C environment
•   4GB or 8GB DDR3L-1333MHz SODIMM on board
•   RJ-45 LAN Port x 4
•   RS-232 serial port
•   USB3.0 port and USB2.0 ports x2
•   On-board CFast slot
•   HDMI Port x 2
•   VESA / DIN-rail mounting options


Applications
•   Machine maker
•   Machine vision
•   Network appliance
•   Digital signage
The ACD-110D from AAEON Technology is an industrial display monitor featuring a 10.1" projected capacitive multi-touch screen, enabling common interactions such as pinch-to-zoom functionality. Its screen offers a resolution of 1280 x 800 in 16:9 aspect ratio. Complying with the power management regulations of VESA DPMS, the ACD-110D is extremely energy efficient and power saving while displaying sharper, more brilliant, crisper and flicker-free images.

Other features include low radiation and near zero electromagnetic fields emissions. The ACD-110D is fully compatible with a PC, and supports DDC1/DDC2B-compliant "Plug & Play" specifications. The on-screen display menu provides user a user-friendly interface to make right adjustment for most optimal display.

The IP65 scratch-proof touchscreen is reinforced to be dust and water resistant. An aluminum front bezel is used to offer a strong yet light enclosure making the ACD-110D significantly slimmer than other contenders in the market. The monitor can be wall mounted or set upright with the provided stand.


Features
•  10.1" WXGA (1280 x 800) TFT LCD display
•  IP65 aluminum front bezel
•  Luminance: 250cd/m2
•  Viewing angle: 160°(H)/160°(V)
•  Supports P-CAP touch screen (two-point multi touch)
•  VGA or DVI-D input signal
•  Mounting options: VESA 75, panel mount, stand kit
•  12VDC with lockable power adapter
•  Dimensions: 265,96 x 183,56 x 40mm


Applications
•  Factory automation
•  In-vehicle entertainment systems
•  Retailer shop
•  Data monitor
The AHP-1154 from AAEON Technology is a fanless 15" XGA touch panel PC power by Intel® Celeron® J1900 2GHz or N2807 1.58GHz processors. This compact, multi-functional and user friendly PC-based system is designed to serve as an operator panel computer in HMI applications.

The AHP-1154 features a TFT LCD display with LED backlight and an 4:3 aspect ratio, an onboard Ethernet controller, multi-COM port interfaces, built-in CFast socket and SATA 2.5" HDD bay. The IP65-rated front plastic bezel & back metal chassis and VESA 75/100 wall mount options, make this "fit anywhere" design very flexible and suitable in many different kinds of installations.



Features
•  Intel® Celeron® J1900 2GHz or N2807 1.58GHz
•  15" 450-nits XGA LED Backlight
•  5-wire resistive touch
•  IP65-rated front plastic bezel & back metal chassis
•  Fanless
•  2 GbE, USB3.0, 3 USB2.0 USB, 2 RS-232, 2 RS-485/422/232, VGA
•  CFast socket, SATA 2.5" HDD bay
•  2 Mini card expansions (full size, half size)
•  VESA 75/100 mounting
•  Supports Windows® 7 32-bit, WES7 32-bit, Windows® 8, Linux Kernel 2.6.x or above



Applications
•  Digital signage
•  Factory automation systems
•  Production process control
•  Kiosk and POS
•  Vending machine
•  Car park automation
The AQ7-BT from AAEON Technology is a 70mm x 70mm Qseven module with Qseven rev.2.0 specification. This board is powered by an Intel® Atom™ E3800 or Celeron® N2807 product family processor SoC with 2GB of onboard DDR3L memory. It accommodates PCI-Express[x1] slots, SMBus, I2C bus, and SDIO interface for expansion.

Furthermore the AQ7-BT features 18/24-bit single-channel LVDS and DDI which can convert to DP/HDMI or other digital display format, GbE Ethernet (depending on SKU); and USB 3.0/2.0, SATA II, and serial ports for I/O.


GET MORE FOR LESS POWERUPGRADES MADE EASYEXCEPTIONAL STORAGE CAPACITY
Offering 4x the performance at 30% less power than its predecessor, the AQ7-BT packs the attributes most sought after in today's energy conscious industry.The small 70x70mm board gives a lot of opportunities, especially for upgrading! Simply remove the old one, pop in a new one and you are ready to go!For storage requirements the AQ7-BT opts for the modern SSDs. With up to 64GB available, it is unparalleled with other competitors on the market.


Features
•  Intel® Atom™ E3800 or Celeron® N2807 series processor SoC
•  Onboard DDR3L 2GB memory
•  18/24-bit single-channel LVDS, DP/HDMI
•  High definition audio interface
•  GbE
•  2 SATA, one shared with onboard SATA SSD (SLC/MLC, up to 32GB)
•  USB3.0 & 6 USB2.0
•  3 PCI-Express [x1]
•  Qseven rev. 2.0, 70 x 70mm



Applications
•  Automation
•  Handheld devices
•  Scientific research
•  Hazmat management
AAEON has launched the embedded single board computer EPIC-BDU7 with the 5th Generation Intel® Core™ Processor.

The EPIC-BDU7 uses the full potential of the processors "Ultra Low Power (ULP) technology", this brings its powerconsumption down to 15W only, that allows fanless configurations.

Graphics capabilities are enhanced with the support for the latest Ultra HD (4k resolution) videos and triple simultaneous display.



Features
•   Onboard 5th Generation Intel ® Core™ i Series ULT Processor SoC
•   DDR3L 1600 MHz SODIMM x 1, Up to 8 GB
•   Gigabit Ethernet x 2, RJ-45 x 2
•   VGA, LVDS, DP, LVDS (Optional), eDP (Optional)
•   SATA 6.0 Gb/s x 2, mSATA/Mini-Card x 1
•   USB 3.0 x 2 , USB 2.0 x 4
•   RS-232 x 4, RS-232/422/485 x 2
•   Optional Touch Screen, TPM and PCI-104
•   Mini-Card x 1, SIM x 1 (Optional)
•   9-24V Operation
•   15W TDP
•   CPU SoC on the bottom + heatspreader


Applications
•   Industrial Control Box
•   Industrial Automation
•   Test & Measurement
•   Security
•   Transportation
•   Defense & Government
The RTC-900B from AAEON Technology is a Windows® 8.1-powered rugged tablet, specifically engineered for on-the-go computing. This 10.1" multi-touch MIL-STD 810G-compliant tablet is equipped with a tempered Gorilla glass-protected LCD that offers 350 nits brightness, 800 nits is optional available. The RTC-900B comes with a scratch, vibration and IP65 water-proof design, and an extended battery life of up to 7 hours.

Built in WiFi, 3G and NFC capabilities provides optimal communication connectivity, also included are physical I/Os including microSD card and USB ports. A smart card reader and TPM module offer additional security. The accompanying dock can be used for charging and provides additional expansion ports (USBs, COM, Ethernet, etc.). 4G technology can be incorporated upon request.

The Windows 8.1-powered tablet offers backward compatibility with legacy software. Its sturdy enclosure helps to minimize accidental damage to its internal components while out in the field. In addition, the robust connectivity features offered by the RTC-900B allows data to be sent and received instantaneously, opening cloud computing options and providing real-time data for advanced fleet management purposes.

The RTC-900R is the Android powered version of this tablet.


Features
•  10.1" WXGA (1280 x 800) TFT LCD display
•  PCAP 10 point multi-touch screen
•  Brightness: 350 nits, 900 nits (Optional)
•  Intel® Atom™ E3825 CPU
•  DDR3L SDRAM 4GB
•  Li-Polymer high capacity battery, 7 hours battery life
•  MIL-STD-810G, IP65 compliant
•  Operating temperature -20°C to +55°C
•  Micro SD card slot, 5M pixel camera
•  WLAN 802.11 a/b/g/n, Bluetooth 4.0
•  GPS navigation, G-sensor, light sensor
•  Windows® Embedded 8.1 Industry Pro


Applications
•  Logistics management
•  Factory automation
•  Fleet management
•  Retail
The EMB-BTx mini-ITX boards from AAEON Technology are powered by the Intel® Bay Trail series processors, offering premium performance and low power consumption. Fanless design is adopted to avoid problems such as vibration and mechanical breakdown. Energy consumption is further reduced with the utilization of ATX power specifications, widely adopted for its stability and versatility, requiring only 12V.

With numerous interface and expansion slots, such as large amount of COM and USB ports and other expansion buses, as well as the presence of LVDS socket(s), Dual LAN and mSATA the EMB-BTx boards are ideally suited for factory automation, kiosk and POS applications. The thin design of the EMB-BT4 is also slim enough to be used in panel PCs and slim PCs.



EMB-BT1

Available CPU versions
Intel Celeron J1900 (4C @ 2.00GHz, 10W TDP)
Intel Celeron N2807 (2C @ 1.58GHz, 4.3W TDP)
Intel Atom E3845 (4C @ 1.91GHz, 10W TDP)
Intel Atom E3825 (2C @ 1.33GHz, 6W TDP)


Specifications
2 SATAIII, 2 SATAII, USB3.0, 7 USB2.0, PCIe [x1], 6 COM, 2 GbE, VGA, HDMI, LVDS, Dual display, Full & Half Mini-Card


EMB-BT2


Available CPU versions
Intel Celeron J1900 (4C @ 2.00GHz, 10W TDP)


Specifications
SATAII, 10 USB2.0, VGA, 2 LVDS, dual displays, PCIe [x1], 8 COM, 2 GBe, Full size Mini-Card


EMB-BT4 COMING SOON!

Available CPU versions
Intel Celeron J1900 (4C @ 2.00 GHz, 10W TDP)
Intel Celeron N2807 (2C @ 1.58 GHz, 4.3W TDP)


Specifications
2 SATA III, 2 SATA II, USB3.0, 7 USB2.0, LVDS, VGA, HDMI, Dual display
6 COM, Gbe, Full & Half Mini-Card

AAEON introduces a new product in the boxer series, the BOXER-6614.
Compared with its predecessor the AEC-6613, the BOXER-6614 features a significantly more powerful processor, the Intel® Celeron® N2930 Quad-core processor running at 1.83GHz and enhanced memory support to DDR3L memory up to 8GB, this gives a performance boost in excess of 38%.

Other enhancements include two RS232/422/485 selectable from BIOS, new USB capabilities supported by USB3.0 and VGA and HDMI supported dual view/simultaneous display, lower power consumption, and OS support for Windows®7/8.1, Windows® Embedded Standard 7/8, Linux Fedora.

Boxer-6614 is a standalone high performance controller designed for long-life operation and with high reliability. It can replace traditional methods and become the mainstream controller for the multimedia entertainment market.


Features
•   Intel® Celeron® N2930 Quad Core 1.83 GHz
•   Intel® Celeron® N2807 Dual Core 1.58 GHz (Optional)
•   Intel® HD Graphics Engine
•   DDR3L 1333 MHz SODIMM slot up to 8 GB
•   HDMI and VGA dual output
•   RS-232/422/485 x2, RS-232 x2
•   USB3.0 and USB2.0 x3
•   Full size PCIe mini card with SIM slot
•   Half size PCIe mini card (for factory-install)
•   GbE x2
•   Low power and compact size
•   Fanless design

Applications
•   Automation and transport industry
•   Petrol stations
•   Cranes
•   Surveillance equipment
•   Multimedia entertainment market
The AEC-6638 from AAEON is a fanless industrial embedded controller based on the 4th generation Intel® Core™ i5 4400E or i3 4100E, running at 37W. This box PC is a standalone high performance reliable controller designed for long-life operation. The AEC-6638 improves upon its predecessor, the AEC-6637, in terms of display capabilities with the Intel® HD Graphics 4600 engine as well as support for VGA, DVI-D and HDMI devices.

The AEC-6638 offers low power consumption and can operate at temperatures ranging from -10° to +50°C. Online capabilities are upgraded through the use of the Intel® chip for greater network stability and security.


Features
•   Intel® Core™ i5-4400E, 2.7 GHz or i3-4100E, 2.4 GHz
•   3 COM Port, 2 USB3.0 & 2 USB2.0
•   2 GbE LAN
•   RS-232/422/485
•   VGA: up to 2048 x 1536 @ 60 Hz
•   DVI-D: 1920 x 1200 @ 60 Hz
•   HDMI: Up to 3840 x 2160 @ 30 Hz
•   2.5" SATA 3 (6.0 Gb/s) HDD drive bay
•   MiniCard or mSATA (selected by jumper setting)
•   DC input: 9 to 30V
•   Operating temperature: -10° to +50°C
•   Fanless operation


Applications
•   Data processing
•   Fleet management
•   Factory automation
The AEC-6950 from AAEON is a highly expandable fanless industrial embedded PC based on the powerful Intel® Core™ i7-3517UE. The rich feature set makes this boxer PC an ideal solution for handling mass data processing and controlling PLC data.

The PCI/PCIe expansion slots provide customers the opportunity to install expansion cards to access and transfer data. The aluminum enclosure supports anti-drop, anti-shock and anti-vibration system protection. The AEC-6950 can withstand tough vibration testing up to 3g rms. Isolated DI/O and multiple power protection, such as OVP, LVP, SVP and RVP help to guard the AEC-6950 from EMI damage. In addition, the AEC-6950 adopts rugged M12 connectors for LAN/ Serial/ USB/ Power ports.

Although the AEC-6950 is compact in size it offers attractive and flexible expansion capabilities such as 4 USB 2.0 ports, 2 USB 3.0 ports, VGA, Audio, 8 COM ports, and 2 PCI or PCI-E [x1].


Features
•   Intel® Core™ i7-3517UE 1.7GHz
•  QM77 chipset
•  COM module integrated
•  2 Expansion slots
•  Isolation DI x4 & DO x4 (3KV)
•  Isolation RS-232/422/485 x2 (3KV)
•  PCI x2 or PCI-E [x1]/ PCI-E [x16]
•  2 GbE
•  SIM Slot on the Mini PCI-E x 2
•  2.5 inch HDD & CFast slot
•  DVI-I
•  Operating temperature: -20° to 50°C
•  Optional: 3G, WiFi, GPS, Bluetooth and CAN bus


Applications
•  Machine control
•  Data processing
•  Fleet & data management
The AEC-6402 from AAEON is an ultra-slim fanless Box PC with extensive I/O capabilities, based on the Intel® Atom™ N2600 1.60 GHz CPU and Intel® NM10 chipset. The AEC-6402 allows up to 2GB of DDR3 1066 SDRAM and a 12V DC power input. I/O capabilities include two USB 2.0 ports, two Gigabit Ethernet ports, two RS-232/422/485 serial ports with RJ-45 connectors, and a CAN bus connector. In addition, there is an option for wireless network connectivity.

The half-size mSATA connection provides high speed solid-state data storage support, enabling analysis of data or high-definition multimedia information via a mini HDMI connector. The tiny light-weight brushed aluminum enclosure provides passive heat dissipation and airflow and can operate in harsh environment with vibrations and temperatures ranging from 0 to +50°C.

The AEC-6402, with longevity support, is an ideal cost-efficient solution for a variety of home automation, factory automation and industrial applications.



Features
•  Intel® Atom™ N2600 1.6 GHz
•  Intel® NM10 Express chipset
•  Dimensions: 125mm x 77mm x 20mm
•  Fanless design
•  Uniform I/O ports: 2x USB2.0 & RJ-45 (Ethernet and COM)
•  Mini-HDMI connector for HDMI output
•  CAN bus 2-pin support
•  Anti-drop power connector design
•  Aluminum enclosure
•  Operating temperature: 0 to +50°C (with airflow)
•  Mounting: wall mount, VESA mount and DIN rail



Applications
•  Factory/machine automation
•  Digital signage
•  Home automation
•  Environmental surveillance
AAEON has released the RTC-700A 7" and RTC-900R 10.1" rugged tablet computer, a computing platform for portable and mobile applications that operate in harsh environments.

The computer is powered by the NVIDIA TEGRA2 1.0 GHz Dual Core processor running the android v4.0/v3.2 operating system and has an intuitive graphic user Interface. They have a high resolution WXGA TFT LCD display with anti-scratch Gorilla™ glass, a projected capacitive multi-touch panel and a high capacity battery.

Features such as a G-sensor, 3-axis digital gyroscope, vibrator motor, light sensor, E-compass and GPS navigation, front and rear camera and micro SD card slot, make the RTC-700A and RTC-900R suitable for all kind of applications that require a portable data input device.

Features
•   NVIDIA TEGRA 2 1.0 GHz Dual Core Processor
•   DDR2 1GB SDRAM
•   WXGA (1280 x 800) TFT LCD display
•   Projected capacitive multi-touch panel, gorilla™ glass
•   Li-Polymer high-capacity battery, 6 hrs. (RTC-700A) 12 hrs. (RTC-900R)
•   Rugged, water and dust proof, IP65 compliance
•   WiFi 802.11 b/g/n, bluetooth R 2.1 + EDR
•   G-Sensor, light sensor, e-compass, GPS navigation
•   Micro SD card slot, 5M pixel camera
•   Android v4.0/v3.2

Optional
•   Sunlight readable
•   Barcode reader 2D/1D
•   MSR / SCR
•   Docking
•   NFC/RFID
•   3G

Applications
•   Industrial
•   Marine
•   Government
•   Business automation
•   Utilities
•   Logistics
•   Professional service
•   Emergency medical service
•   Transportation
•   Field services
The fanless 21.5" ACP-5217 from AAEON is a multi-touch infotainment panel PC with Intel® Core™ i7/i5/Celeron® processor and Intel QM77 chipset. The panel has a full HD (1920x1080) TFT LCD display with an IP65 waterproof front bezel, anti-scratch multi-touch projected capacitive touch screen and IPX1 back cover which provides protection against spilled liquids.

The ACP-5217 supports a 2.5" SATA hard disk drive, CFast™ slot for the storage functions, and a mini card expansion.

The rich optional accessories such as RFID, magnetic stripe reader, barcode scanner, bluetooth, skype phone and a WiFi antenna, makes the ACP-5217 ideal for public infotainment and digital signage applications.

Features
•   21.5" Full HD (1920 x 1080) fanless TFT LCD display
•   Easy-To-Clean: multi-touch window design (two-point)
•   Intel Core™ i7/i5/ Celeron processor
•   IP-65 front bezel & IPx1 back chassis from the top
•   Anti-scratch surface (7H hardness)

Optional accessories
•   RFID module
•   Smart card reader
•   Wireless module (b/g/n)
•   Magnetic stripe reader (MSR)
•   Barcode scanner
•   Camera

Applications
•   Multi-Touch
•   Infotainment
•   Retailer
The GENE-QM87 from AAEON is a 3.5" SubCompact board powered by the advanced low power consumption Intel® Haswell i5-4402E CPU and companion Intel QM87 chipset. This board offers superb graphic performances with 3D performance via Intel InTru™ 3D Technology and Clear Video HD Technology, rich connectivity, 3 independent displays with Full HD support, 4 display interfaces, remote management through iAMT 9.0 and Rapid Storage Technology.

The GENE-QM87 supports lower power 204-pin DDR3L 1333/1600 system memory with a maximum capacity of 8GB. Measuring at a mere 146mm x 101.6mm in size, it features a rich array of I/O interfaces and extensions.

Whenever Microsoft® Windows® platform is used, customers can easily create their own user interface without additional coding simply by downloading the AAEON Hi-Safe program. The GENE-QM87 supports all common operating systems such as Windows XP, Windows 8 and 7, Linux Fedora and legacy embedded Operating Systems.


Features
•   Intel® dual core 1.6 GHz Core i5-4402E Haswell CPU @ 25W TDP
•  Intel® QM87
•  SODIMM DDR3L 1333/1600, max. 8GB
•  Gigabit ethernet x 2, RJ-45 x 2
•  Triple independent monitor support\
•  Full HD, excellent 3D performance
•  CRT, DVI, 18/24-bit dual-channel LVDS LCD x 2, HDMI
•  2CH HD audio
•  SATA 6.0Gb/s x 2 (optional RAID), CFast x 1
•  USB3.0 x 2, USB2.0 x 6, COM x 4, 8-bit Digital I/O
•  Mini Card x 1
•  +12V only operation
•  Supports iAMT with Intel® QM87
•  Onboard 4/5/8-wire resistive touch screen controller
•  AAEON Hi-Safe/SDK/utility supported
•  x 1 (optional, would replace mini card by jumper setting)


Applications
•  Industrial automation
•  Gaming & entertainment
•  Multimedia
•  Digital signage
The ACD-521M from AAEON Technology is a slim 21.5" Full HD infotainment multi-user and multi-touch display with cutting-edge Multi-User technology, Projected Capacitive Multi-Touch panel, IP65 waterproof front bezel and durable 7H hardnesss anti-scratch glass. With this state-of-the-art Multi-User technology, the system host computer is able to share resources with up to 20 users simultaneously to help save on hardware, LAN development and manpower maintenance costs.

The ACD-521M offers two-finger multi-touch for easy zooming and friendly front panel buttons for display settings. With a 16:9 aspect ratio, default resolution of 1920x1080 and stunning 16.7M colors, the ACD-521M is well-suited for watching Full HD.

Another advantage over consumer displays is the non-gap IP65 rated front bezel design and IPx1 water protected back chassis, making the ACD-521M more durable against accidental spills and dust. The ACD-521M supports cloud computing technology with complete computing processing functions (No CPU/OS/memory/HDD).


Features
•  21.5" (1920 x 1080) fanless TFT LCD display
•  Projected Capacitive Multi-Touch screen
•  Built-in Multi User technology
•  IP65 certified front bezel and IPx1 rear chassis
•  Anti-scratch surface (7H hardness)
•  Flexible expansion interfaces
•  Supports common OS in the market
•  G-Sensor support


Applications
•  Retail store signage
•  Hospitality services
•  Industrial automation
•  Infotainment
•  High-precision manufacturing
The COM-QM87 from Aaeon is one of the new product models with the 4th generation Intel® Core™. This board is a type 6 COM Express CPU module, has a mobile Intel® QM87 Express chipset, offering low-power and enhanced graphic power compared to AAEON's previous COM Express CPU modules.

The two SODIMM sockets support up to 16GB of DDR3 memory. Storage requirements are easily through the 4 SATA 3.0 ports.
The Intel® Gigabit Ethernet controller together with the I/O interfaces of the Type 6 COM Express takes care for quick networking application.

With built-in visual engines, supported by the 4th generation Intel® Core ™ i7/i5 processors, the COM-QM87 has faster HD video streaming and processing ability for up to three simultaneous.

Features
•  Onboard 4th Generation Intel® Core™ i7/i5/i3
•  Intel® QM87 PCH
•  Dual-channel SODIMM DDR3L (16GB max)
•  GbE (iAMT 9.0 Support)
•  CRT, 18/24-bit Dual-channel LVDS, eDP
•  4x SATA III
•  4x USB3.0, 8x USB2.0
•  PCIe[x16], 7x PCIe[x1]
•  COM Express basic module

Applications
•  Healthcare
•  Retail & advertising
•  Test & measurement
•  Gaming & entertainment
•  Industrial automation
•  Security
•  Defense & government
•  Digital signage



Back to top of page
© Texim Europe 2009 - 2017. All rights reserved.     Disclaimer - Cookies - Terms of Delivery - Customs - AEO Certificate
Facebook Button    Twitter Button    Linkedin Button    Google Plus Button
